Technical parameters
| Dimensions | 600*510*480mm |
|---|---|
| Working size | 300*400*80mm |
| Workpiece height | 100mm |
| Material | 6061-Т6 Aluminum |
| Screw | Import 1605 Ball Screw |
| Runners | Round Guide |
| Spindle power | 500W DC motor |
| Spindle Driver | Speed controller |
| Spindle speed | 0 – 8000rpm/min / 0 – 24000rpm/min |
| Spindle Cooling | Air / Water cooling |
| Spindle collet | ER11-6mm |
| Stepper motor | 57BYH56-4011YD |
| Stepper driver | 8 division driver |
| Support code | Standard G code, nc, tab,mmg, Plt, eng, dxf etc. |
| The accuracy of engraving | ±0. 03mm |
| Repeat accuracy | ±0. 02mm |
| Software | mach3/USB |
| Communication | LPT/PCl/usb |
