Technical parameters
| Dimensions | 1200*780*580mm |
|---|---|
| Working size | 600*900*125mm |
| Workpiece height | 125mm |
| Material | 6061-Т6 Aluminum |
| Screw | Import 1605 Ball Screw |
| Runners | Round Guide |
| Spindle power | Spindle motor 800W/1500W/2000W DC |
| Spindle Driver | VFD |
| Spindle speed | 0 – 24000rpm/min |
| Spindle Cooling | Water cooling |
| Spindle collet | ER11-6mm |
| Stepper motor | 57BYH56-4011YD |
| Stepper driver | 8 division driver |
| Support code | Standard G code, nc, tab, mmg, Plt, eng, dxf etc. |
| The accuracy of engraving | ±0. 03mm |
| Repeat accuracy | ±0. 02mm |
| Software | mach3/USB |
| Communication | LPT/PCl/usb |
| Voltage | AC220V/110V/UNIVERSAL |
| Program Compatibility | Mach3/ТYPE5/МasterСАM/CDR/UG /ARTCAM/Coppercam/CAD/CAM/ Etc. |
